27. March 2025

Bruker introduces a new EBSD detector for advanced materials characterization

eWARP combines direct electron detection and CMOS technologies

EBSD detector eWARP © Bruker

Bruker announces the launch of eWARP, a new detector for Electron Backscatter Diffraction (EBSD) that marks the advent of a new era in EBSD technology. Featuring a revolutionary Bruker-engineered camera that combines direct electron detection and CMOS technologies, the new eWARP (Wide ARea Pixelated sensor) is the fastest and most signal efficient EBSD detector ever, significantly pushing the limits for materials characterization in Scanning Electron Microscopes (SEM).

Unlike other EBSD detectors in the market that are utilizing off-the-shelf sensors for direct electron detection, eWARP’s hybrid pixel sensor and high-speed signal-processing electronics have been designed using a first principles approach, with EBSD-specific requirements in mind. As a result, eWARP vastly outperforms existing solutions, especially in terms of signal efficiency and acquisition speed, providing users with game-changing new analytical opportunities.

Combined with the ESPRIT software suite, eWARP enables the acquisition of EBSD maps with up to 14,400 patterns per second at electron beam settings as low as 10 kV accelerating voltage and 12 nA probe current. At the core of eWARP sits the patented first ever CMOS device with on-sensor binning capability. When operated in binning mode, the sensor performs Forescatter Electron (FSE) and Backscatter Electron (BSE) imaging with up to 350,000 patterns per second.

This quantum leap in performance will have a transformational impact on the future potential of the EBSD technique, especially when it comes to challenging applications for which high spatial resolution, low electron energy and/or short exposure time are critically important. For instance,

  • automated acquisition of 3D EBSD data can now be done in much less time, at higher pixel resolution or covering a larger volume,
  • the characterization of ultra-fine grained or heavily deformed materials will greatly benefit from spatial resolution improvements down to 20 nm while still operating at ultra-high speed,
  • time-resolved EBSD mapping, i.e. the acquisition of repetitive maps and images every few seconds, will become feasible, helping to understand microstructural changes inside materials during in-situ heating and/or mechanical testing experiments.

Beyond its superior analytical performance, eWARP’s revolutionary design also guarantees minimized cost of ownership and maximized uptime due to remote detector monitoring for preventive/predictive maintenance, the field-replaceable camera module and user upgradable firmware for future performance and functionality improvements.

“We are so excited to introduce the eWARP, a new product that embodies our dedication to innovation and excellence,” said Dr. Daniel Goran, Senior Product Manager EBSD at Bruker. “Enabling entirely new levels of performance in terms of data acquisition, we are confident the resulting new analytical capabilities and higher productivity will help to significantly further increase the adoption of the EBSD technique in academia and industry.”

More information: www.bruker.com/eWARP



About Bruker Corporation

Bruker is enabling scientists and engineers to make breakthrough post-genomic discoveries and develop new applications that improve the quality of human life. Bruker’s high performance scientific instruments and high value analytical and diagnostic solutions enable scientists to explore life and materials at molecular, cellular, and microscopic levels. In close cooperation with our customers, Bruker is enabling innovation, improved productivity, and customer success in post-genomic life science molecular and cell biology research, in applied and biopharma applications, in microscopy and nanoanalysis, as well as in industrial and cleantech research, and next-gen semiconductor metrology in support of AI. Bruker offers differentiated, high-value life science and diagnostics systems and solutions in preclinical imaging, clinical phenomics research, proteomics and multiomics, spatial and single-cell biology, functional structural and condensate biology, as well as in clinical microbiology and molecular diagnostics.

Media contact:

Sandra Vodene
Head of Performance Marketing
Bruker Nano GmbH
+49 30 670990-0
sandra.vodene(at)bruker.com
www.bruker.com



Press release, 26 March 2025

Analytics Photonics / Optics
