03. June 2022

Mixing laser- and x-ray-beams

A team of researchers from MBI and DESY observed a new kind of wave mixing process involving soft x-rays

Light beams © Anne Riemann/FVB
Two light beams from flashlights will not be influenced by each other when they cross. This is different for very intense laser pulses which meet in a suitable “nonlinear material” – here, beams can be deflected and new beams of different color can be created in a process called wave-mixing. The observation of such wave-mixing phenomena allows researchers to draw conclusions about electronic transitions within the nonlinear material which are otherwise invisible. Researchers from MBI and DESY have now observed how an x-ray beam interacts with a laser beam, paving a route to atom-selective studies of ultrafast processes in the future. | Credit: Anne Riemann/FVB

Unlike fictional laser swords, real laser beams do not interact with each other when they cross – unless the beams meet within a suitable material allowing for nonlinear light-matter interaction. In such a case, wave mixing can give rise to beams with changed colors and directions.

Wave-mixing processes between different light beams are one cornerstone of the field of nonlinear optics, which is firmly established since lasers have become widely available. Within a suitable material such as particular crystals, two laser beams can “feel each other’s presence”. In this process, energy and momentum can be exchanged, giving rise to additional laser beams emerging from the interaction zone in different directions and with different frequencies, in the visible spectral range seen as different colors. These effects are commonly used to design and realize new laser light sources. Just as important, the analysis of the emerging light beams in wave mixing phenomena provides insights into the nature of the material in which the wave mixing process occurs. Such wave-mixing based spectroscopy allows researchers to understand intricacies of the electronic structure of a specimen and how light can excite and interact with the material. So far, however, these approaches have been hardly used outside of the visible or infrared spectral range.

A team of researchers from Max Born Institute (MBI), Berlin, and DESY, Hamburg, has now observed a new kind of such wave mixing process involving soft x-rays. Overlapping ultrashort pulses of soft x-rays and infrared radiation in a single crystal of lithium fluoride (LiF), they see how energy from two infrared photons is transferred to or from the x-ray photon, changing the x-ray “color” in a so-called third-order nonlinear process.

Not only do they observe this particular process with x-rays for the first time, they were also able to map out its efficiency when changing the color of the incoming x-rays. It turns out that the mixing signals are only detectable when the process involves an inner-shell electron from a lithium atom being promoted into a state where this electron is tightly bound to the vacancy it left behind – a state known as exciton. Furthermore, comparison with theory shows that an otherwise “optically forbidden” transition of an inner-shell electron contributes to the wave mixing process.

Via analysis of this resonant four-wave mixing process, the researchers get a detailed picture of where the optically excited electron travels in its very short lifetime. “Only if the excited electron is localized in the immediate vicinity of the hole it has left behind do we observe the four-wave mixing signal”, says Robin Engel, a PhD student involved in the work, “and because we have used a specific color of x-rays, we know that this hole is very close to the atomic nucleus of the lithium atom”.

Due to the ability of x-rays to excite inner shell electrons selectively at the different atomic species in a material, the demonstrated approach allows researchers to track electrons moving around in molecules or solids after they have been stimulated by an ultrafast laser pulse. Exactly such processes – electrons moving towards different atoms after having been excited by light – are crucial steps in photochemical reactions or applications such as light harvesting, e.g., via photovoltaics or direct solar fuel generation. “As our wave-mixing spectroscopy approach can be scaled to much higher photon energies at x-ray lasers, many different atoms of the periodic table can be selectively excited. In this way we expect that it will be possible to track the transient presence of electrons at many different atoms of a more complex material, giving new insight into these important processes”, explains Daniel Schick, researcher at MBI.


Publication

Probing electron and hole colocalization by resonant four-wave mixing spectroscopy in the extreme ultraviolet
Horst Rottke, Robin Y. Engel, Daniel Schick, Jan O. Schunck, Piter S. Miedema, Martin C. Borchert, Marion Kuhlmann, Nagitha Ekanayake, Siarhei Dziarzhytski, Günter Brenner, Ulrich Eichmann, Clemens von Korff Schmising, Martin Beye, Stefan Eisebitt
Science Advances, Vol. 8, Issue 20 (2022). URL, DOI oder PDF


Contact:

Max Born Institute for Nonlinear Optics and Short Pulse Spectroscopy
Prof. Dr. Stefan Eisebitt
Phone +49 30 6392-1300
Email eisebitt(at)mbi-berlin.de
www.mbi-berlin.de

Deutsches Elektronen-Synchrotron DESY
Dr. Martin Beye
Email martin.beye(at)desy.de
desy.de



Press release MBI, 19 May 2022
